SKF
BearingCOP.222S100M-2SRS
SKF Cooper split spherical roller bearing, sealed
Specifications
| Bore (d) | 100.000 mm |
| Outer Diameter (D) | 200.000 mm |
| Width (B) | 84.000 mm |
| Seal Type | Open |
| Bearing Type | Spherical Roller |
| Dynamic Load (C) | 320.000 kN |
| Static Load (C₀) | 410.000 kN |
| Speed — Grease | — |
| Speed — Oil | 405 RPM |
| Temperature Range | -30°C to 120°C |
| Rows | 1 |
Split spherical roller bearings are completely split to the shaft for easy maintenance and simplification of shaft systems. Generally, they can dimensionally replace non-split spherical roller bearings mounted on adapter sleeves, re-using the existing housings for minimum disturbance of machine alignment. The incorporation of seals into the bearing offers an additional barrier to contaminant ingress, providing exceptional sealing capability in combination with the housing seals.
