SKF
BearingS71908 ACB/P4A
Super-precision, high-speed B design, single row angular contact ball bearing with seals
Specifications
| Bore (d) | 40.000 mm |
| Outer Diameter (D) | 62.000 mm |
| Width (B) | 12.000 mm |
| Seal Type | Open |
| Bearing Type | Angular Contact |
| Dynamic Load (C) | 5.070 kN |
| Static Load (C₀) | 3.900 kN |
| Speed — Grease | — |
| Speed — Oil | — |
| Temperature Range | -30°C to 120°C |
| Rows | 1 |
These super-precision, high-speed, single row angular contact ball bearings, with 25° contact angle, with seals, accommodate radial and axial loads acting simultaneously, where the axial load acts in one direction only. Compared to the equivalent SKF E design high-speed bearings, these are suited for lighter loads.
